Project Description

DERBY STATION REMODELLING

Derby Station Footbridge 3d CAD Model

Location

Derby Railway Station, UK

Surveying Equipment

Leica P40 Scanner
Total Station

Deliverables

3D CAD Model

As part of the Derby Station remodelling programme there was a requirement for an as-built of a new footbridge. The bridge was scanned both externally and internally using a Leica P40 scanner and controlled by targets tied to the existing Derby station co-ordinate system. The scans were registered and processed using Leica Cyclone software, the data was then imported into AutoCAD for the creation of a 3D model, which was subsequently inserted into the Derby Station BIM Master drawing.
